small capacity melting induction furnace

FOB Reference Price:Get Latest Price
$5,000.00 - $10,000.00 / Set | 1 Set/Sets (Min. Order)
Model Number:
Induction Furnace
Lead Time:
Quantity(Sets) 1 - 50 >50
Est. Time(days) 30 Negotiable
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Place of Origin:
Shanghai, China
Type:
Induction Furnace
Usage:
Melting Furnace, Melting Furnace
Brand Name:
Shanghai Fortune
Voltage:
380, 415V
Dimension(L*W*H):
up to the model
Certification:
ISO, CE, ISO, CE
Weight (T):
0.15 T
Power (kW):
160
Warranty:
1 Year, 12 months
After-sales Service Provided:
Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Online support
Applicable Industries:
Manufacturing Plant
crucible type:
Graphite, Magnesia
Rated temperature:
1650 degress Celsius
Power:
15~160kw
Frequency:
50 or 60hz
Capacity:
1~500 kg
Melting time:
30~60 mins
Application:
Copper ,brass ,aluminum ,steel,silve
Supply Ability
Supply Ability:
500 Set/Sets per Month
Packaging & Delivery
Packaging Details
plywood cases
Port
Shanghai
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 50 >50
Est. Time(days) 30 To be negotiated
Product Description



small capacity induction furnace sale



Application:

Small electric melting furnace for copper scarp are mainly used for the melting of steel, stainless steel, copper, brass, silver, gold ,glass and aluminium materials, etc. Melting capacity can be from 3KG to 500KG.



Feature:



1. Easy to install and operate.  No need make foundation or any civil work.
2. Super small size and portable, occupies not enough 1.0 square meters.
3. 24 hours no-stop melting ability.
4. Energy saving and environmental protection.
5. It's easy to change furnace to melt different materials.

6. Using crucible: No need skilled person for making lining by refractory material as the normal by           induction furnace

7. With digital display of working frequency, current, voltage, power




Technical Parameters:



1.Melting ability



Model

Maximum input powerMelting ability of common materials
Steel and stainless steelBrass,   copper,   silver,   goldAluminium
IGBT-1515KW3KG10KG3KG
IGBT-2525KW5KG20KG5KG
IGBT-3535KW10KG30KG10KG
IGBT-4545KW18KG50KG18KG
IGBT-7070KW25KG100KG25KG
IGBT-9090KW40KG120KG40KG
IGBT-110110KW50KG150KG50KG
IGBT-160160KW100KG250KG100KG



small capacity induction furnace sale



 2. Installation Drawing









Packaging & Shipping

Packaging & Shipping



♦ Package: One piece in one plywood case

♦ Shipping: By Sea









small capacity induction furnace sale
